Antenna families
See below the list with all the Family of radar antenna systems CHL offers;
Family |
Length |
Gain |
Frequency band |
Polarization |
Vertical radiation pattern |
|
 |
SB (Blue Line) |
8-13 ft |
≥ 31 dB |
X-band |
V or C |
Fan beam |
 |
SL (Silver Line) |
18 ft |
≥ 34 dB |
X-band |
H, or C |
Fan beam |
 |
S |
18-31 ft |
≥ 35-36 dB |
X-band |
V |
Quasi inverse cosec2 |
 |
SN |
18-21 ft |
≥ 34 dB |
X-band |
H,V or C |
Fan beam |
 |
SG (Green line) |
18-24 ft |
≥ 36 dB |
X-band |
H,V or C |
Fan beam |
 |
SGX39 |
≥ 39 dB |
X-band |
H, V or C |
Fan beam |
|
 |
SGX44 |
≥ 44 dB |
X-band |
H, V or C |
Fan beam |
|
|
SHV |
18-24 ft |
≥ 39 dB |
X-band |
H/C, V/C or H/V/C switchable |
Quasi inverse cosec2 |
 |
SV107 (S-band) |
21 ft |
≥ 31 dB |
S-band |
V |
Fan beam |
| Ku45 | 15 ft |
≥ 40 dB |
Ku-band |
C |
Quasi inverse cosec2 to -15º [-35º] |
The radar antenna you require is not listed?
We design and build radar antenna systems to your specifications.
